Longfian Oxygen Concentrator JAY-05 Dual Flow 5-Liter

Longfian Oxygen Concentrator JAY-05 Dual Flow 5-Liter

The Longfian JAY-05 Dual Flow Oxygen Concentrator is a heavy-duty, 5-liter stationary medical device that utilizes Pressure Swing Adsorption (PSA) technology to extract and deliver high-purity medical oxygen.

Primary Medical Uses

• Chronic Obstructive Pulmonary Disease (COPD) & Pulmonary Fibrosis: Provides high-flow, continuous oxygen therapy necessary for patients with advanced or severe chronic restrictive and obstructive lung diseases.
• Simultaneous Multi-Patient Support (Dual Flow): Equipped with two independent flow meters and outlets, allowing two users to receive oxygen therapy at the same time (e.g., splitting a 5L capacity or custom configurations for twin setups in home care or clinical rooms).
• Clinical & Hospital Ward Use: Deployed in smaller medical clinics, nursing homes, and step-down hospital wards where piped oxygen systems are unavailable.
• Post-Surgical Recovery & Palliative Care: Supports patients requiring extended supplemental oxygen during postoperative recovery or palliative comfort care.
• Combination with Sleep Therapy: Compatible with CPAP or BiPAP systems for patients needing concurrent respiratory support for obstructive sleep apnea coupled with hypoxemia.

Key Technical Specifications

• Flow Rate: 0.5 to 5 LPM (Liters Per Minute), adjustable.
• Oxygen Concentration: Maintained at 93% (-+3%) across all flow settings.
• Outlet Pressure: 0.04 – 0.07 MPa (approx. 6–10 psi).
• Operation Capacity: Engineered for continuous 24/7/365 reliable operation backed by an integrated cooling system.
• Safety Monitoring: Features comprehensive digital and audible alarms for power failure, high/low pressure cycles, and low oxygen purity drops.
